Roland V 7 Piece Electric Drumkit

Kit Configuration:

• Drum sound module: TD-02 x 1
• Snare: PD-4 x 1
• Tom: PD-4 x 3
• Hi-Hat: CY-5 x 1
• Hi-Hat control pedal: FD-1 x 1
• Crash: CY-5 x 1
• Ride: CY-5 x 1
• Kick: KT-1 x 1
• Drum Stand: MDS-MINI x 1

---

Drum Kits:

• 16 drum kits

---

Coach Functions (5 modes):

• Time Check (easy)
• Time Check (hard)
• Quiet Count
• Auto Up/Down
• Change-Up

---

Metronome:

• Tempo: 20–260
• Rhythm Types: 5 types
• Sounds: 15 types

---

Display:

• 16 Characters x 2 Lines LCD (with backlight)

---

Connectors:

• OUTPUT/PHONES Jack: Stereo Miniature Phone Type
• MIX IN Jack: Stereo Miniature Phone Type
• USB COMPUTER Port: USB B Type
• TRIGGER INPUT Connector: DB-25 Type (Kick, Snare, Tom 1, Tom 2, Tom 3, Hi-Hat, Crash 1, Crash 2, Ride, Hi-Hat Control)
• Bluetooth ADAPTOR SLOT: Bluetooth(R) Audio MIDI Dual Adaptor (MODEL BT-DUAL)

---

USB COMPUTER:

• Speed: Full-speed USB (Generic), Hi-Speed USB (Vendor)
• Driver Mode: Generic, Vendor
• Protocol: USB MIDI, USB Audio *2

---

USB Audio:

• Sampling Rate (original): 44.1 kHz
• Sampling Rate (with sampling rate converter): 96 kHz, 48 kHz
• Record: 2 Channels
• Playback: 2 Channels

---

Power Supply:

• AC Adaptor (DC 12 V)

---

Current Draw:

• 200 mA

---

Accessories:

• Setup Guide
• Leaflet "USING THE UNIT SAFELY"
• AC Adaptor
• Special Connection Cable
• Drum Key

---

Options (Sold Separately):

• Additional Crash Cymbal (Crash 2): OP-TD1C
• Snare: PDX-6, PDX-8 *3
• Kick: KD Series
• Personal Drum Monitor: PM Series
• V-Drums Accessory Package: DAP-2X
• V-Drums Mat: TDM Series
• Noise Eater: NE Series
• Bluetooth(R) Audio MIDI Dual Adaptor (MODEL BT-DUAL)

---

Size and Weight:

• Width: 1,000 mm / 39-3/8 inches (Including the drum throne)
• Depth: 1,100 mm / 43-5/16 inches (Including the drum throne)
• Height: 1,150 mm / 45-5/16 inches (Including the drum throne)
• Weight: 12.1 kg / 26 lbs 11 oz

---

Notes:

• *1 Drum throne, drumsticks, and headphones are not included.
• *2 In order to use USB audio, switch to vendor mode and use the vendor driver.
• *3 The MDH-Standard is required to attach the PDX-6 and the PDX-8.
